YI PLASTIC ANTI UV&IR Polycarbonate sheets can prevent 100% of UV damage to the human body, plants, animals and atmosphere.
It can
YIPLASTIC ANIT UV&IR Polycarbonate sheets can isolat 100% of UV damage to human body,effectively isolate temperature transmission,achieve constant temperature performance,superior impact resistance,fight against high-altitude parabolliceffective safety protection,20 years of super Long warranty,is the replacement of outdoor PC board.
Artificial accelerated aging experiments confirm the results.
Conclusion: The co-extruded UV protective layer has the strongest protective effect on the board
Artificial weathering (Xe-WOM procedure),
700 hrs = 1 year of Europe outdoor weathering
Light transmittance comparable to glass
Control light transmittance as needed
Soft and even light transmission – diffuse
Effectively limits solar heat penetration
Protects skin, cornea, and organic materials from fading
Unbreakable, used for roof and side lighting in buildings, replacing safety glass
Light transmission applications
UV-blocking layer for heritage protection
THE COMPANY PRODUCTS HAVE PASSED SGS EU BUILDING MATERIALS FIRE DETECTION AND ROSH INSPECTION
YIPLASTIC Corrugated Polycarbonate Sheet meets the V0 or V2 fire rating according to UL94. Therefore, it can be used for household products, architecture, and transportation fields.
Restriction Of Hazardous Substances
YIPLASTIC offers environmentally-friendly Corrugated polycarbonate sheets and meets RoHS standards in Europe.
The first advantage as the name indicates is being anti-ultraviolet radiation and anti-infrared radiation. It is very easy to handle and install. They can be used as a safety helmet for welding and fire procedures.
YI PLASTIC products using advanced technology make the surface UV layer over 50 μm, wear 2 um per year conversion, so the YI PLASTIC products can reach more than 20 years.
YIPLASTIC ANIT UV&IR Polycarbonate sheets can isolat 100% of UV damage to human body,effectively isolate temperature transmission,achieve constant temperature performance,superior impact resistance,fight against high-altitude parabolliceffective safety protection,20 years of super Long warranty,is the replacement of outdoor PC board.
It is stronger than aluminum and has less weight than it. It is the best to use for varnishing and glazing.
Comes with UV protection to prevent any radiation hazard. Strong and can survive thrashing.
It is weather resistant and ensures the best performance in severe weather either hot or cold conditions. Chemical resistant and very easy to handle and install. It is bendable to any shape.
| THICKNESS mm | WEIGHK(g/m2) | LIGHT TRANSTTANCE ％(ASTM D1003) | Shock strength J/m (ASTM D256) | Sound Isoluation (DB) | Standard Width(mm) | Standard Length(mm) | Standard Color |
| 2 | 2.4 | 88 | 900 | 22 | 1210 1560 1810 2100 | 3000 | Clear, Opal Blue , Green Bronze |
| 3 | 3.6 | 87 | 930 | 24 | |||
| 4.5 | 5.4 | 86 | 1100 | 27 | |||
| 6 | 7.2 | 85 | 1300 | 28 | |||
| 8 | 9.6 | 84 | 1400 | 30 | |||
| 10 | 12 | 82 | 1500 | 32 | |||
| 12 | 14.4 | 81 | 1600 | 34 | |||
| 15 | 18 | 36 | |||||
| 18 | 21.6 | 37 | |||||
| 20 | 24 | 37 |
Remarks:
More features of Soild polycarbonate sheets:
•Simply installed
•Light weight
•Avoid alot and sound insulation
•Light weight and high wind resistance
•Impact resistance
•Temperature range:-40~+120°C
| PHYSICALPROPERTY TABLE | |||
| PROPERTY | TEST METHOD | UNITS | VALUE |
| PHYSICAL | |||
| Specific Gravity | ASTM D792 | g/cm² | 1.2 |
| Light Transmission | ASTM D1003 | % | 45-92 |
| Water Absorption Equilibrium,24HRS | ASTM D570 | % | 0.35 |
| MECHANICAL | |||
| Tensile Strength | ASTM D882 | Mpa | ≥60 |
| Elongation Ultimate | ASTM D882 | % | ≥90 |
| THERMAL | |||
| Vicat Sofrening Temperature | ASTM D1525 | ° c | 135 |
| Strain Telief@135°C | ASTM D1204 | % | ≤l |
| ELECTRICAL | |||
| Diectric Strength(@10mils) | ASTMD 149 | KV/MM | ≥30 |
| Volume Resistvity@25° C,50%RH | ASTMD 257 | Ω-cm | >1X10′ |
| Surface Resistvity@25° C,50%RH | ASTMD257 | Q | >1X10′ |
| FLAMMABILITY | |||
| Burning behaviorUL94UL94(1.5mm) | Class | HB | |
| UL94UL94(0.75mm) | Class | V-2 | |
| PRODUCE MACHINE | PRODUCE MACHINE | PRODUCT WIDTH | THICKNESs |
| BREYER② GERMAN BREYER IINE | POLYCARBONATESHEETS | 1350mm | 1.0-8.0mm |
| Layer | Tranditional PC sheets | Yiplastic polycarbonate sheets | ||
| UV Isolation Layer |
|
| ||
| impact resistant layer | Due to the addition of anti-uv particles in the PClayer, the layer has impurities, thus reducing itsimpact resistance. | Pure PC layer,thus exerting theoretical maximum impactresistance. YIPLASTIC products use Germany production line,the solidroller than domestic equipment using hollow roller heat evenlymolding pressure, molecular arrangement more tidy,make sheetdensity increased,thereby enhancing product impact resistance. | ||
| Nano thermalinsulation layer | No | YIPLASTIC products with German nano insulation factor high-pressureco-extrusion form the insulating layer, the maximum to preventheat passing through an infrared ray,can effectively guaranteethe indoor, shed an inferior build this product local temperature,constant temperature effect. |
| Model | Clear | Bronze | White opal | Glass Green | lake blue | Opalecent | Brown | Sliver Gray | Gray | Diffuse milky white | Milky white translucent | Custom Color |
| 2 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 3 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 4.5 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 6 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 8 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 10 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 12 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 15 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 18 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 20 | ✔ | ✔ | ✔ | ✔ | ✔ |
1.The telephone booth, advertising board, light boxes advertising, exhibition layout Instrument, meter, high voltage switch cabinet panel, LED panel board and military industry
2.highway and urban elevated road noise barriers
3.Office building, department store, hotels, villas, schools, hospitals, stadiums, entertainment center and public facilities lighting ceiling
4.advertising street signs, light box advertising, display and exhibition arrangements; for instruments, meters, high and low voltage switchgear panels,
5.canopies, carports, waiting sheds and other light and rain shelters.
6.agricultural greenhouse and breeding shed and ecological restaurant
7.Subway entrances, railway stations, car parks, shopping centers, shelters, rest rooms, corridors canopy
8.Bank security counter, jewelry store anti-theft window, police riot shields airports, safety glazing material plant Advertising light panel, advertising display cards, decorative walls
Home, office interior space, walkways, fence, balcony, shower room sliding door
Yes, they are specially designed to protect from UV and IR rays hazards
YI PLASTIC products use a German production line, they have a tidier molecular arrangement which increases the sheet density and enhances the impact resistance of the product.
Other’s polycarbonate layers have several impurities due to the count of anti-UV particles in the which decreases the impact resistance, while ours is a pure polycarbonate layer that has maximum impact resistance.
Yes, our anti UV and IR polycarbonate sheets come with a super-duper 20 years long warranty from manufacturers.
Yes, it comes with both anti IR and UV protection.
Yes, they protect humans, animals birds and animals as well.
No, it comes with a 10-year super long warranty
It has a high-density anti-UV layer, polycarbonate shock resistance layer and a Nano infrared thermal insulation layer.
YIPLASTIC is a global leading manufacturer of high quality polycarbonate sheets and processing products,
Our 42000sqm and 5 imported lines are established in 2004 in china, we supply OEM AND ODM Marketing with high quality for all over the world.
