Yiplastic Light diffusion polycarbonate sheets are hard and light-weighted sheets having exceptional visual characteristics.
And has high transmittance,good printing performance and excellent physical and mechanical properties. It also has thermal stability, insulation and flame retardancy.
YIPLASTIC ANIT UV&IR Polycarbonate sheets can isolat 100% of UV damage to human body,effectively isolate temperature transmission,achieve constant temperature performance,superior impact resistance,fight against high-altitude parabolliceffective safety protection,20 years of super Long warranty,is the replacement of outdoor PC board.
Artificial accelerated aging experiments confirm the results.
Conclusion: The co-extruded UV protective layer has the strongest protective effect on the board
Artificial weathering (Xe-WOM procedure),
700 hrs = 1 year of Europe outdoor weathering
Light transmittance comparable to glass
Control light transmittance as needed
Soft and even light transmission – diffuse
Effectively limits solar heat penetration
Protects skin, cornea, and organic materials from fading
Unbreakable, used for roof and side lighting in buildings, replacing safety glass
Light transmission applications
UV-blocking layer for heritage protection
Product | DESCRIPTION/MAIN FEATURES | THICKNE(mm) |
Polycarbonate Solid Sheet | Good workability and plasticity. | 0.7-3.0 |
THE COMPANY PRODUCTS HAVE PASSED SGS EU BUILDING MATERIALS FIRE DETECTION AND ROSH INSPECTION
YIPLASTIC Corrugated Polycarbonate Sheet meets the V0 or V2 fire rating according to UL94. Therefore, it can be used for household products, architecture, and transportation fields.
Restriction Of Hazardous Substances
YIPLASTIC offers environmentally-friendly Corrugated polycarbonate sheets and meets RoHS standards in Europe.
√ Optical properties: YiPlastics light-diffusing polycarbonate sheets have worthy light diffusion and outstanding transmission of LED hot spots.
√ Durability: They have a very high degree of impact resistance as well as very good heat resistance properties.
√ Adaptability: These polycarbonate sheets spread light equally all over the material. They are highly fire-resistant. They are made to withstand any weather condition, thus highly weather resistant. They are customizable to any size.
| THICKNESS mm | WEIGHK(g/m2) | LIGHT TRANSTTANCE ％(ASTM D1003) | Shock strength J/m (ASTM D256) | Sound Isoluation (DB) | Standard Width(mm) | Standard Length(mm) | Standard Color |
| 2 | 2.4 | 88 | 900 | 22 | 1210 1560 1810 2100 | 3000 | Clear, Opal Blue , Green Bronze |
| 3 | 3.6 | 87 | 930 | 24 | |||
| 4.5 | 5.4 | 86 | 1100 | 27 | |||
| 6 | 7.2 | 85 | 1300 | 28 | |||
| 8 | 9.6 | 84 | 1400 | 30 | |||
| 10 | 12 | 82 | 1500 | 32 | |||
| 12 | 14.4 | 81 | 1600 | 34 | |||
| 15 | 18 | 36 | |||||
| 18 | 21.6 | 37 | |||||
| 20 | 24 | 37 |
Remarks:
More features of Soild polycarbonate sheets:
•Simply installed
•Light weight
•Avoid alot and sound insulation
•Light weight and high wind resistance
•Impact resistance
•Temperature range:-40~+120°C
| PHYSICALPROPERTY TABLE | |||
| PROPERTY | TEST METHOD | UNITS | VALUE |
| PHYSICAL | |||
| Specific Gravity | ASTM D792 | g/cm² | 1.2 |
| Light Transmission | ASTM D1003 | % | 45-92 |
| Water Absorption Equilibrium,24HRS | ASTM D570 | % | 0.35 |
| MECHANICAL | |||
| Tensile Strength | ASTM D882 | Mpa | ≥60 |
| Elongation Ultimate | ASTM D882 | % | ≥90 |
| THERMAL | |||
| Vicat Sofrening Temperature | ASTM D1525 | ° c | 135 |
| Strain Telief@135°C | ASTM D1204 | % | ≤l |
| ELECTRICAL | |||
| Diectric Strength(@10mils) | ASTMD 149 | KV/MM | ≥30 |
| Volume Resistvity@25° C,50%RH | ASTMD 257 | Ω-cm | >1X10′ |
| Surface Resistvity@25° C,50%RH | ASTMD257 | Q | >1X10′ |
| FLAMMABILITY | |||
| Burning behaviorUL94UL94(1.5mm) | Class | HB | |
| UL94UL94(0.75mm) | Class | V-2 | |
| PRODUCE MACHINE | PRODUCE MACHINE | PRODUCT WIDTH | THICKNESs |
| BREYER② GERMAN BREYER IINE | POLYCARBONATESHEETS | 1350mm | 1.0-8.0mm |
| Layer | Tranditional PC sheets | Yiplastic polycarbonate sheets | ||
| UV Isolation Layer |
|
| ||
| impact resistant layer | Due to the addition of anti-uv particles in the PClayer, the layer has impurities, thus reducing itsimpact resistance. | Pure PC layer,thus exerting theoretical maximum impactresistance. YIPLASTIC products use Germany production line,the solidroller than domestic equipment using hollow roller heat evenlymolding pressure, molecular arrangement more tidy,make sheetdensity increased,thereby enhancing product impact resistance. | ||
| Nano thermalinsulation layer | No | YIPLASTIC products with German nano insulation factor high-pressureco-extrusion form the insulating layer, the maximum to preventheat passing through an infrared ray,can effectively guaranteethe indoor, shed an inferior build this product local temperature,constant temperature effect. |
| Model | Clear | Bronze | White opal | Glass Green | lake blue | Opalecent | Brown | Sliver Gray | Gray | Diffuse milky white | Milky white translucent | Custom Color |
| 2 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 3 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 4.5 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 6 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 8 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 10 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 12 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 15 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 18 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 20 | ✔ | ✔ | ✔ | ✔ | ✔ |
It is widely used in optical lenses.mechanical baffles,craft gifts, home TV windows and other related fields.
It is suitable for instruments, instruments, high and low voltage switchgear panels,
LED panels and military industries, and for deep processing such as thermoforming,plastic absorption,etc.
Yes, you can make any kind of customized box or showcase from it
Yes, you can select from our available colors from our specifications tab
The answer could be yes or no. If it is a simple design we might make it for you but we can give you all the materials for a complex design.
Yes, our available phone numbers are ….
YiPlastics light-diffusing polycarbonate sheets have worthy light diffusion and outstanding transmission of LED hot spots.
These polycarbonate sheets spread light equally all over the material.
Yes, they are made to withstand any weather condition, thus highly weather resistant.
Yes, they can be used in chandeliers
YIPLASTIC is a global leading manufacturer of high quality polycarbonate sheets and processing products,
Our 42000sqm and 5 imported lines are established in 2004 in china, we supply OEM AND ODM Marketing with high quality for all over the world.
