YiPlastics flame retardant sheet is a self-fire-extinguishing sheet. It is an unbreakable anti UV radiation polycarbonate sheet.
It is much stronger than glass. They can be fabricated very easily.
It can be used in many industries.
It is being used in aircraft, and current-carrying items because of its self-extinguishing characteristics to get rid of any fire hazards.
YIPLASTIC ANIT UV&IR Polycarbonate sheets can isolat 100% of UV damage to human body,effectively isolate temperature transmission,achieve constant temperature performance,superior impact resistance,fight against high-altitude parabolliceffective safety protection,20 years of super Long warranty,is the replacement of outdoor PC board.
Artificial accelerated aging experiments confirm the results.
Conclusion: The co-extruded UV protective layer has the strongest protective effect on the board
Artificial weathering (Xe-WOM procedure),
700 hrs = 1 year of Europe outdoor weathering
Light transmittance comparable to glass
Control light transmittance as needed
Soft and even light transmission – diffuse
Effectively limits solar heat penetration
Protects skin, cornea, and organic materials from fading
Unbreakable, used for roof and side lighting in buildings, replacing safety glass
Light transmission applications
UV-blocking layer for heritage protection
THE COMPANY PRODUCTS HAVE PASSED SGS EU BUILDING MATERIALS FIRE DETECTION AND ROSH INSPECTION
YIPLASTIC Corrugated Polycarbonate Sheet meets the V0 or V2 fire rating according to UL94. Therefore, it can be used for household products, architecture, and transportation fields.
Restriction Of Hazardous Substances
YIPLASTIC offers environmentally-friendly Corrugated polycarbonate sheets and meets RoHS standards in Europe.
They are the ideal choice for projects with fire hazards and high-temperature applications. They have high light diffusion as well as flawless clarity and temperature resistance.
It is very durable and ideal for electronics. They are weatherproof and water-resistant.
They have high heat formability and are easily printable.
It is stronger than aluminum and has less weight than it. It is the best to use for varnishing and glazing.
Comes with UV protection to prevent any radiation hazard. Strong and can survive thrashing.
It is weather resistant and ensures the best performance in severe weather either hot or cold conditions. Chemical resistant and very easy to handle and install. It is bendable to any shape.
| THICKNESS mm | WEIGHK(g/m2) | LIGHT TRANSTTANCE ％(ASTM D1003) | Shock strength J/m (ASTM D256) | Sound Isoluation (DB) | Standard Width(mm) | Standard Length(mm) | Standard Color |
| 2 | 2.4 | 88 | 900 | 22 | 1210 1560 1810 2100 | 3000 | Clear, Opal Blue , Green Bronze |
| 3 | 3.6 | 87 | 930 | 24 | |||
| 4.5 | 5.4 | 86 | 1100 | 27 | |||
| 6 | 7.2 | 85 | 1300 | 28 | |||
| 8 | 9.6 | 84 | 1400 | 30 | |||
| 10 | 12 | 82 | 1500 | 32 | |||
| 12 | 14.4 | 81 | 1600 | 34 | |||
| 15 | 18 | 36 | |||||
| 18 | 21.6 | 37 | |||||
| 20 | 24 | 37 |
Remarks:
Easy processing :Polycarbonate panels can be cut directly with a common saw, drilled with a common drill bit, and cold bent,Cold bending, punching and thermoforming are possible for solid sheets up to 6 mm in thickness
•Simply installed
•Light weight
•Avoid alot and sound insulation
•Light weight and high wind resistance
•Impact resistance
•Temperature range:-40~+120°C
| PHYSICALPROPERTY TABLE | |||
| PROPERTY | TEST METHOD | UNITS | VALUE |
| PHYSICAL | |||
| Specific Gravity | ASTM D792 | g/cm² | 1.2 |
| Light Transmission | ASTM D1003 | % | 45-92 |
| Water Absorption Equilibrium,24HRS | ASTM D570 | % | 0.35 |
| MECHANICAL | |||
| Tensile Strength | ASTM D882 | Mpa | ≥60 |
| Elongation Ultimate | ASTM D882 | % | ≥90 |
| THERMAL | |||
| Vicat Sofrening Temperature | ASTM D1525 | ° c | 135 |
| Strain Telief@135°C | ASTM D1204 | % | ≤l |
| ELECTRICAL | |||
| Diectric Strength(@10mils) | ASTMD 149 | KV/MM | ≥30 |
| Volume Resistvity@25° C,50%RH | ASTMD 257 | Ω-cm | >1X10′ |
| Surface Resistvity@25° C,50%RH | ASTMD257 | Q | >1X10′ |
| FLAMMABILITY | |||
| Burning behaviorUL94UL94(1.5mm) | Class | HB | |
| UL94UL94(0.75mm) | Class | V-2 | |
| PRODUCE MACHINE | PRODUCE MACHINE | PRODUCT WIDTH | THICKNESs |
| BREYER② GERMAN BREYER IINE | POLYCARBONATESHEETS | 1350mm | 1.0-8.0mm |
| Layer | Tranditional PC sheets | Yiplastic polycarbonate sheets | ||
| UV Isolation Layer |
|
| ||
| impact resistant layer | Due to the addition of anti-uv particles in the PClayer, the layer has impurities, thus reducing itsimpact resistance. | Pure PC layer,thus exerting theoretical maximum impactresistance. YIPLASTIC products use Germany production line,the solidroller than domestic equipment using hollow roller heat evenlymolding pressure, molecular arrangement more tidy,make sheetdensity increased,thereby enhancing product impact resistance. | ||
| Nano thermalinsulation layer | No | YIPLASTIC products with German nano insulation factor high-pressureco-extrusion form the insulating layer, the maximum to preventheat passing through an infrared ray,can effectively guaranteethe indoor, shed an inferior build this product local temperature,constant temperature effect. |
| Model | Clear | Bronze | White opal | Glass Green | lake blue | Opalecent | Brown | Sliver Gray | Gray | Diffuse milky white | Milky white translucent | Custom Color |
| 2 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 3 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 4.5 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 6 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 8 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 10 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 12 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 15 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 18 | ✔ | ✔ | ✔ | ✔ | ✔ | |||||||
| 20 | ✔ | ✔ | ✔ | ✔ | ✔ |
Office building ceiling, department stores, hotels, villas, schools, hospitals, stadiums, recreation centers and public facilities
Highway, rail and urban elevated road noise barriers
Subway entrances, railway stations, car parks, shopping centers, shelters, rest rooms, corridors canopy
Bank security counter, jewelry store anti-theft window, police riot shields airports, safety glazing material plant Advertising light panel, advertising display cards, decorative walls
Home, office interior space, walkways, fence, balcony, shower room sliding door
Instrument accessories, display screen and military industry, mechanical shutter
Yes, they are the same polycarbonate sheets
Yes, with proper supervision or experience, this is the best polycarbonate sheet to use.
Yes, you can have it in any customized shape and design.
No, they are self-extinguishing too. They are an anti-fire hazard.
Yes, they will self-extinguish.
Yes, they are a crucial part of aircraft mechanisms.
Yes, they can be used on advertising boards.
Yes, they are highly temperature resistant.
YIPLASTIC is a global leading manufacturer of high quality polycarbonate sheets and processing products,
Our 42000sqm and 5 imported lines are established in 2004 in china, we supply OEM AND ODM Marketing with high quality for all over the world.
