YIPLASTIC ANTI-FOG Polycarbonate sheet is fully compliant with the fire protection standards for materials used in public buildings, as it is well below the smoke toxicity limits, it is self-extinguishing after leaving the fire, and the molten droplets do not burn. Multi-wall polycarbonate panels are the best choice for many applications in the field of architecture and design, such as curtain walls, stadiums, railway stations, industrial plants and other kinds of building roofs, sound barriers, interior decoration, safety protection, etc.
The reason why multi-wall polycarbonate sheets are so convincing is that they are not only beautiful and elegant. It is because they are not only beautiful and generous in appearance. These two points alone make them superior to many traditional building materials, and they also have strong functional and intelligent characteristics, saving energy and reducing energy costs while achieving environmental protection.
When the temperature difference between the inside and outside of the greenhouse and the indoor humidity reach a critical value, the water vapor must be condensed on the roof and walls on the inside of the greenhouse to form a droplet.
Falling fog drops damage plants while reducing light transmission
For polycarbonate sheets without anti-fog drop function, due to the surface tension of water, water will condense into small water droplets and adhere to the surface of the sheet.
As the water droplets condense, they will gather and become large water droplets.
The anti-fog Panels reduces the tension between the water droplets and the plate through a special material bonded to the surface of the plate, so that the condensed water flows directly along the inside of the polycarbonate plate, and no water droplets are generated, thereby preventing the light transmittance from falling and avoiding dripping.
Yiplastic Polycarbonate sheets offer a 10-year limited warranty to ensure your normal use.
The physicochemical properties of organic materials will change after prolonged weather and sunshine. However, the patented UV layer coextrusion technology is applied to the polycarbonate sheet to ensure the stability of various physical and chemical properties during the warranty period.
KEY TECHNOLOGY
● UV layer thickness
● Uniformity of thickness of UVlayer
The quality control system ensures a uniform UV protection layer of 50μm.
The UV protective layer determines important anti-aging parameters such as the transmittance and yellow index of the polycarbonate sheet. We use expensive UV raw materials to ensure your long-term use. The figure below shows a comparison of the UV-free polycarbonate sheet, the UV-coated polycarbonate sheet and the yellow index. It shows that the co-extruded UV polycarbonate sheet has stable properties.
THE COMPANY PRODUCTS HAVE PASSED SGS EU BUILDING MATERIALS FIRE DETECTION AND ROSH INSPECTION
YIPLASTIC Corrugated Polycarbonate Sheet meets the V0 or V2 fire rating according to UL94. Therefore, it can be used for household products, architecture, and transportation fields.
Restriction Of Hazardous Substances
YIPLASTIC offers environmentally-friendly Corrugated polycarbonate sheets and meets RoHS standards in Europe.
Fogging can be a big problem when using heat insulators for visual impacts. They are small water droplets condensing on any solid surface and make it difficult to see the insights. To solve the problem of blurry visuals, Yi Plastics is offering the best anti-fog polycarbonate sheets. They are chosen by construction companies, architects, designers and greenhouse companies. The properties include:
Our anti-fog polycarbonate sheets are fully fire resistant and protectant also with a very beautiful and glossy appearance
It is designed to be energy-saving for the low cost of electricity and low power consumption. This function makes it environment friendly too. It saves energy and also saves the planet in the best way possible.
It has a delicate and powerful Anti-fog coating to prevent blurriness and ensure a clear view. The Highest quality hydrophilic coating proves to be the best for water resistance. You don’t have to be worried about water droplets and fog coming into the way of your vision anymore. Our Anti-scratch properties are the cherry on top.
Our anti-fog polycarbonate sheets are also humidity free. They are thermally stable and work the same in every weather condition. They are highly flexible and can fit anywhere.
We are offering custom sizes and specifications for our polycarbonate sheets. Customizable aspects are available on our website. They ate available in many colors, you can pick your favorite at our Colours tab.
| Type | Thickness(mm) | Color type | Max width (mm) | Length(mm) | Density | Light transmisson | K VALUE | Min Cold Bend Radius (mm) |
| Twin-wall PC sheets | 4 | Clear Opalecent Grass green lake blue Gray Brown | 2100 mm | NO LIMITED | 0.9 | 80 | 4.1 | 700 |
| 6 | 1.1 | 80 | 3.5 | 1050 | ||||
| 8 | 1.5 | 80 | 2.9 | 1400 | ||||
| 10 | 1.7 | 79 | 2.8 | 1750 | ||||
| Three-wall PC Sheets | 8 | 1.7 | 73 | 2.6 | 1400 | |||
| 10 | 1.9 | 73 | 2.4 | 1750 | ||||
| 12 | 2.1 | 72 | 2.4 | 2100 | ||||
| 16 | 2.5 | 72 | 2.2 | 2800 | ||||
| Three-wall x structure PC sheet | 16 | Clear | 2.5 | 62 | 2.0 | Not recommended | ||
| Opalecent | ||||||||
| 25 | Sliver Gray | 3.5 | 55 | 1.7 | ||||
| Five-wall x structure PC sheet | 40 | Clear | 1500 | 4.7 | 45+-5 | 1.1 | ||
| Diffuse milky white | 11+-5 | |||||||
| Five-wall plug structure PC sheet | 40 | Milky white translucent | 1570 | 4.7 | 23+-5 |
Remarks:
These features are favored by architects, designers, construction companies and greenhouse companies.
| Item | Unit | Technical requirements | ||
| Falling hammer impact (perforation characteristics) | Maximum penetration force | N | ≥600 | |
| Maximum penetration energy | ≥5 | |||
| Falling hammer impact (50% impact damage energy) | ≥15 | |||
| Thermal expansion coefficient | ℃-1 | ≤3.5×10-5 | ||
| Weathering performance (6000h) | light transmittance reduction | ≤6.0 | ||
| Yellow index change | ≤10.0 | |||
| Heat transfer coefficien | d=8mm(twin-hollow) | W/(m2. K) | ≤3.3 | |
| d=10mm(twin-hollow) | ≤3.0 | |||
| d=10mm(three-hollow) | ≤2.8 | |||
| UV transmittance ratio | ≤0.001 | |||
| burning performance | grade | less than B grade | ||
| Model | Clear | Bronze | White opal | Glass Green | lake blue | Opalecent | Brown | Sliver Gray | Gray | Diffuse milky white | Milky white translucent | Custom Color |
| Twin-wall PC sheets | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | |||
| Three-wall PC Sheets | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | |||
| Three-wall x structure PC sheet | ✔ | ✔ | ✔ | ✔ | ||||||||
| Five-wall plug structure PC sheet | ✔ | ✔ |
TRANSMITTANCE
| MATERIAL | TRANSMITTANCE(%) |
| SINGLELAYER GLASS | 92 |
| 11OMM TWIN -WALL HOLLOW SHEET | 77 |
| Material Name | Heat transfer coefficient | Material Name | Heat transfer coefficient |
| （W/m2 ·K) | （W/m2 ∙K) | ||
| 6mm glass | 5.8 | 6 mm single polycarbonate sheet | 4.8 |
| 3＋3（3）Insulating glass | 4.09 | 8mm polycarbonate sheet | 2.9 |
| 3＋3（6）Insulating glass | 3.17 | 10mm polycarbonate sheet | 2.8 |
| 6＋6（6）Insulating glass | 3.06 | 16mm polycarbonate sheet | 2.2 |
| 3＋3（12）Insulating glass | 2.91 | 16mm polycarbonate sheet | 2.2 |
| 6＋6（12）Insulating glass | 2.8 | 25mm polycarbonate sheet | 1.7 |
Yes, they are specially coated with anti-scratch and anti-fog layers.
No, the anti-fog layer is a very delicate layer that helps your sheets be fog-free. It does not affect the quality and weight of the sheets.
No. the anti-fog coating layers are not permanent.
Yes, we make sheets in customized dimensions per order.
Yes, we can also coat your other sheets no matter flat or multilayer with your desired anti-fog and anti-scratch coating.
UV Coating Layer is 50µm in thickness.
The Standard Size is 0.5 – 14mm (customizable).
Yes, they are humidity-free too along with anti-fog.
YIPLASTIC is a global leading manufacturer of high quality polycarbonate sheets and processing products,
Our 42000sqm and 5 imported lines are established in 2004 in china, we supply OEM AND ODM Marketing with high quality for all over the world.
